FEATURES :

One-stop automatic intelligent temperature control: in different environment, user does not need to change setting due to it will automatically
switch to appropriate operating temperature.
CW-5300AH : applied to cool two 150W CO2 glass laser tube;
CW-5300AI :applied to a cool single 200W CO2 glass laser tube, a single 100W laser diode, a single 50W-75W solid-state laser or a single 100W RF laser tube;
CW-5300AK :applied to a cool single 100W laser diode, a single 18KW CNC spindle or welding equipment;
CW-5302 : double water inlets and outlets series (optional); Heat booster (optional)
Model
 CW-5300AH CW-5300BH CW-5300DH CW-5300AI CW-5300BI CW-5300DI CW-5300AK CW-5300BK CW-5300DK
Voltage
 AC220~240V AC208~230V AC100~110V AC220~240V AC208~230V AC100~110V AC220~240V AC208~230V AC100~110V
Frequency
 50Hz 60Hz 60Hz 50Hz 60Hz 60Hz 50Hz 60Hz 60Hz
Current
 0.8~4.2A 0.8~4.2A 1~6A 1~4.5A 1~4.5A 2~8A 1~4.5A 1~4.5A 2~8A
Compressor power 0.615KW 0.895KW 0.68KW 0.615KW 0.895KW 0.68KW 0.615KW 0.895KW 0.68KW
0.8HP 1.2HP 0.91HP 0.8HP 1.2HP 0.91HP 0.8HP 1.2HP 0.91HP

Refrigerating capacity

 6138Btu/h 6138Btu/h 6138Btu/h
1.8KW 1.8KW 1.8KW
1547Kcal/h 1547Kcal/h 1547Kcal/h
Refrigerant
 R-22/R-410a
Refrigerant charge
 650g
Reducer Capillary
Precision ±0.3℃
Protection Overcurrent protection for compressor, flow alarm, over temperature alarm
Pump power 0.05KW 0.1KW 0.05KW
Tank capacity 12L
Inlet and outlet Rp1/2"
Max. lift 12M 25M 70M
Max. flow 13 L/min 16 L/min 5 L/min
N.W 44 Kgs 46 Kgs
G.W 50 Kgs 52 Kgs
Dimension 53 X 38 X 74 cm (L x W x H)
Package dimension 67 X 51 X 93 cm (L x W x H)
