FEATURES :
CW-3000AG: applied to cool a single 80W CO2 glass laser tube (emitting rate lower than 60%); |
MODEL
|
CW-3000AG | CW-3000DG | CW-3000AF | CW-3000DF | CW-3000AK | CW-3000DK |
---|---|---|---|---|---|---|
Voltages
|
AC220~240V | AC100~120V | AC220~240V | AC100~120V | AC220~240V | AC100~120V |
Frequency
|
50/60Hz | |||||
Current
|
0.45A | 0.9A | 0.45A | 0.9A | 0.5A | 1.0A |
Radiating capacity
|
50W/℃ | 60W/℃ | ||||
Tank capacity
|
9 L | |||||
Inlet and outlet
|
External Φ 10mm brass connector |
Φ 10mm brass connector
|
Φ 6mm speedy connector
|
|||
Max. lift
|
10 M | 70M | ||||
Max. flow
|
10 L/min | 2 L/min | ||||
Protection
|
Flow alarm | |||||
N.W
|
9.5Kg | 12Kg | ||||
G.W
|
12Kg | 14.5Kg | ||||
Dimensions |
47 X 27 X 37 cm (L x W x H) | |||||
Packing dimensions |
59 X 38 X 47 cm (L x W x H) |
