FEATURES :

One-stop automatic intelligent temperature control:in different environment, user does not need to change setting due to it will automatically
switch to appropriate operating temperature.
CW-5200AG: applied to cool a single 150W CO2 glass laser tube or two 100W CO2 glass laser tubes;
CW-5200AI : applied to a cool single 50W-75W laser diode, a single 15W-30W solid-state laser or a single 30W RF laser tube;
CW-5200AK:applied to a cool single 50W-75W laser diode, a single 8KW CNC spindle or welding equipment;
CW-5202 : double water inlets and outlets series (optional); Heat booster (optional)

Model
 CW-5200AG CW-5200BG CW-5200DG CW-5200AI CW-5200BI CW-5200DI CW-5200AK CW-5200BK CW-5200DK
Voltage
 AC220~240V AC208~230V AC100~110V AC220~240V AC208~230V AC100~110V AC220~240V AC208~230V AC100~110V
Frequency
 50Hz 60Hz 60Hz 50Hz 60Hz 60Hz 50Hz 60Hz 60Hz
Current
 2.4~3.1A 2.6~3.3A 4.5~6.5A 2.4~3.1A 2.6~3.3A 4.5~6.5A 2.4~3.1A 2.6~3.3A 4.5~6.5A
Compressor power 0.52KW 0.5KW 0.68KW 0.52KW 0.5KW 0.68KW 0.305KW 0.38KW 0.305KW
0.71HP 0.68HP 0.93HP 0.71HP 0.68HP 0.93HP 0.71HP 0.68HP 0.93HP

Refrigerating capacity

 5084Btu/h 4982Btu/h 5186Btu/h 5084Btu/h 4982Btu/h 5186Btu/h 5084Btu/h 4982Btu/h 5186Btu/h
1.49KW 1.46KW 1.52KW 1.49KW 1.46KW 1.52KW 1.49KW 1.46KW 1.52KW
1281Kcal/h 1256Kcal/h 1307Kcal/h 1281Kcal/h 1256Kcal/h 1307Kcal/h 1281Kcal/h 1256Kcal/h 1307Kcal/h
Refrigerant
 R-22/R-410a/R-134a
Refrigerant charge
 360g 380g 350g 360g 380g 350g 360g 380g 350g
Reducer Capillary
Precision ±0.3℃
Protection Overcurrent protection for compressor, flow alarm, over temperature alarm
Pump power 0.03KW 0.1KW 0.05KW
Tank capacity 6L
Inlet and outlet External Φ10mm brass connector Internal Φ8mm speedy connector
Max. lift 10 M 25 M 70 M
Max. flow 10 L/min 16 L/min 5 L/min
N.W 30 Kgs 33 Kgs
G.W 35 Kgs 38 Kgs
Dimension 55 X 28 X 43 cm (L x W x H)
