FEATURES :

One-stop automatic intelligent temperature control:in different environment, user does not need to change setting due to it will automatically switch
to appropriate operating temperature.
CW-6200AH: applied to cool two 200W CO2 glass laser tube;
CW-6200AI : applied to cool a single 200W RF laser tube or a single 600W CO2 glass laser tube;
CW-6200AN: applied to cool a single 400W laser diode, a 200W solid-state laser, a single 600W-1000W fiber lasers or a single 45KW CNC spindle;
CW-6202 : double water inlets and outlets series (optional); Heat booster (optional).

Model CW-6200AH CW-6200BH CW-6200DH CW-6200AI CW-6200BI CW-6200DI CW-6200AN CW-6200BN CW-6200DN
Voltage AC220~240V AC208~230V AC100~110V AC220~240V AC208~230V AC100~110V AC220~240V AC208~230V AC100~110V
Frequency 50Hz 60Hz 60Hz 50Hz 60Hz 60Hz 50Hz 60Hz 60Hz
Current 1~8.2A 1~9A 1~10A 2~9A 2~10A 2~10.5A 2~9A 2~10A 2~10.5A
Compressor power 1.55KW 1.645KW 1.135KW 1.55KW 1.645KW 1.135KW 1.55KW 1.645KW 1.135KW
2.11HP 2.24HP 1.54HP 2.11HP 2.24HP 1.54HP 2.11HP 2.24HP 1.54HP

Refrigerating capacity

17190Btu/h 17640Btu/h 11533Btu/h 17190Btu/h 17640Btu/h 11533Btu/h 17190Btu/h 17640Btu/h 11533Btu/h
5.04KW 5.17KW 3.38KW 5.04KW 5.17KW 3.38KW 5.04KW 5.17KW 3.38KW
4333Kcal/h 4446Kcal/h 2907Kcal/h 4333Kcal/h 4446Kcal/h 2907Kcal/h 2907Kcal/h 4446Kcal/h 2907Kcal/h
Refrigerant R-22/R-410a
Refrigerant charge 1100g 1200g 1000g 1100g 1200g 1000g 1100g 1200g 1000g
Precision Capillary
Reducer ±0.3℃
Protection Overcurrent protection for compressor, flow alarm, over temperature alarm
Pump power 0.05KW 0.1KW 0.55 KW
Tank capacity 15 L
Inlet and outlet Rp1/2"
Max. lift 12 M 25 M 28 M
Max. flow 13 L/min 16 L/min 58 L/min
N.W 69 Kgs 82 Kgs
G.W 79 Kgs 92 Kgs
Dimension 60 X 47 X 89 cm (L x W x H)
Package dimension 70 X 60 X 109 cm (L x W x H)
